我司是ALPS授權代理商，ALPS系列產品均有在售，需要了解價格、包裝數，交期以及產品資料請咨詢?cè)诰€客服！
|
產品編號 |
照片 |
切換時限 |
行程 |
全行程 |
動作力 |
安裝方法 |
電路數 |
按鍵形狀 |
動作 |
端子形狀 |
尺寸(W×D×H) |
|
SPPH110800 |
 |
Non shorting |
1.5mm |
2.5mm |
2(+1, -0.7)N |
PC board |
2 |
Standard |
Latching |
Straight |
10.0×10.0×8.5mm |
|
SPPH110300 |
 |
Non shorting |
1.5mm |
2.5mm |
2(+1, -0.7)N |
PC board |
2 |
Standard |
Momentary |
Straight |
10.0×10.0×8.5mm |
|
SPPH120400 |
 |
Non shorting |
1.5mm |
2.5mm |
2(+1, -0.7)N |
PC board |
2 |
Short |
Latching |
Straight |
10.0×10.0×8.5mm |
|
SPPH120100 |
 |
Non shorting |
1.5mm |
2.5mm |
2(+1, -0.7)N |
PC board |
2 |
Short |
Momentary |
Straight |
10.0×10.0×8.5mm |
|
SPPH130400 |
 |
Non shorting |
1.5mm |
2.5mm |
2(+1, -0.7)N |
PC board |
2 |
Standard |
Latching |
Snap-in |
10.0×10.0×8.5mm |
|
SPPH130100 |
 |
Non shorting |
1.5mm |
2.5mm |
2(+1, -0.7)N |
PC board |
2 |
Standard |
Momentary |
Snap-in |
10.0×10.0×8.5mm |
|
SPPH140300 |
 |
Non shorting |
1.5mm |
2.5mm |
2(+1, -0.7)N |
PC board |
2 |
Short |
Latching |
Snap-in |
10.0×10.0×8.5mm |
|
SPPH140100 |
 |
Non shorting |
1.5mm |
2.5mm |
2(+1, -0.7)N |
PC board |
2 |
Short |
Momentary |
Snap-in |
10.0×10.0×8.5mm |
|
SPPH110900 |
 |
Non shorting |
1.5mm |
2.5mm |
3(+1, -0.7)N |
PC board |
2 |
Standard |
Latching |
Straight |
10.0×10.0×8.5mm |
|
SPPH130500 |
 |
Non shorting |
1.5mm |
2.5mm |
3(+1, -0.7)N |
PC board |
2 |
Standard |
Latching |
Snap-in |
10.0×10.0×8.5mm |
|
SPPH140400 |
 |
Non shorting |
1.5mm |
2.5mm |
3(+1, -0.7)N |
PC board |
2 |
Short |
Latching |
Snap-in |
10.0×10.0×8.5mm |
SPEH1系列用途：
Audio / TV:畫面, 音響, 專業音響
Automotive:汽車導航儀 汽車音響 HVAC
