我司是ALPS授權代理商，ALPS系列產品均有在售，需要了解價格、包裝數，交期以及產品資料請咨詢?cè)诰€(xiàn)客服！
|
產品編號 |
照片 |
型 |
動作力 |
操作方向 |
行程 |
產品高度 |
操作壽命(5mA 12V DC) |
初期接觸電阻 |
防水及防塵型 |
按鈕顏色 |
尺寸(W×D×H) |
|
SKRAAWE010 |
 |
Surface mount |
0.6N |
Top push |
0.3mm |
3.5mm |
4,000,000 cycles |
100mΩ max |
- |
Blue |
6.2×6.2×3.5 |
|
SKRAAKE010 |
 |
Surface mount |
2.45N |
Top push |
0.3mm |
3.5mm |
100,000 cycles |
100mΩ max |
IP67 |
White |
6.2×6.2×3.5 |
|
SKRAALE010 |
 |
Surface mount |
3.92N |
Top push |
0.35mm |
3.5mm |
100,000 cycles |
100mΩ max. |
IP67 |
White |
6.2×6.2×3.5 |
|
SKRAAME010 |
 |
Surface mount |
1.96N |
Top push |
0.5mm |
5.1mm |
100,000 cycles |
100mΩ max. |
IP67 |
White |
6.2×6.2×5.1 |
|
SKRAAQE010 |
 |
Surface mount |
3.43N |
Top push |
0.55mm |
5.1mm |
100,000 cycles |
100mΩ max. |
IP67 |
Blue |
6.2×6.2×5.1 |
|
SKRABCE010 |
|
Surface mount |
1.2N |
Top push |
0.4mm |
3.5mm |
3,000,000 cycles |
100mΩ max. |
- |
Blue |
6.2×6.2×3.5 |
|
SKRABGE010 |
 |
Surface mount |
2.0N |
Top push |
0.25mm |
3.5mm |
2,000,000 cycles |
100mΩ max. |
IP67 |
White |
6.2×6.2×3.5 |
SKRA系列用途：
Mobile:筆記本電腦&周邊設備
Energy / Industrial:機器人 無人機, 工業設備, 轉換器
Game:家庭用便攜設備, VR AR
Healthcare:健康器具, 介護器具, 分析 檢查器具
Home:白色家電, 辦公設備
Automotive:轉向, 換檔器, 頂置控制臺, 汽車導航儀 汽車音響 HVAC
